Denon AVR-887 User Manual

Advanced Setup – Part 1 Advanced Setup – Part 1
56
ENGLISH
ENGLISH
Setting the Dolby Digital Downmix Option
Setup
Turn the audio compression on or off when down-mixing Dolby Digital
signals.
Press
DD HH
to select “Dolby Digital Setup”, then press
ENTER.
Press
FF GG
to set.
ON:
The dynamic range is compressed automatically according to the
combination of speakers being used.
Set “Compression” to “ON” if it seems that sound is distorted
because the input level exceeds the allowable input for the front
speakers.
OFF:
The dynamic range is not compressed.
Normally using in this mode.
Press ENTER.
1
2
3
• When a center speaker or surround speakers are not connected, the
sounds in those channels are directed to the front speakers.
1
2
1
2
3
4
Advanced Playback
Setting the 2ch Direct/Stereo
Make the 2-channel direct mode and stereo mode speaker settings.
Press
DD HH
to select “Advanced Playback”, then press
ENTER.
Press
DD HH
to select “2ch Direct / Stereo”, then press
ENTER.
• The current settings are displayed.
1
2
3
Press
DD HH
to select the item, then press
FF GG
to set.
For a description of the settings for the different items, see
pages 60 ~ 63.
Basic:
The “Speaker Setup” settings are displayed.
Custom:
The speaker settings for the 2-channel direct and stereo modes can
be changed.
4
Press ENTER.
5
Press
FF GG
to select “Basic” or “Custom”.

Denon AVR-887 Specifications

Power

rated output front	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output front alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output center	100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output center alternative	135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output surround	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output surround alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output surround back	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output surround back alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
power supply	AC 120 V, 60 Hz
power consumption	5.5 A

Audio Inputs and Outputs

analog inputs	9 sets
analog ext inputs	8
digital inputs optical	4
digital inputs coaxial	2
audio delay function	0 - 200 msec.
variable subwoofer crossover	40/60/80/90/100/110/120/150/200/250 Hz

Video Inputs and Outputs

component video inputs	3 sets
composite inputs	5
s-video inputs	5
component video outputs	1 set
composite outputs	3
s-video outputs	3

Audio Performance

frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	100 dB (IHF-A weighted)
tone control treble	±6 dB at 10 kHz
tone control bass	±6 dB at 100 Hz

Weight and Dimensions

dimensions	17-3/32” (W) x 6-47/64” (H) x 16-27/64” (D)
dimensions metric	434 (W) x 171 (H) x 417 (D) mm
weight	29 lbs 5 oz
weight metric	13.0 kg
