Denon AVR-887 User Manual

ENGLISH
ENGLISH
Operating the remote control unit Operating the remote control unit
66
Operating a component stored in the preset
memory
Operate the component.
For details, refer to the component’s operating instructions.
Some models cannot be operated with this remote control unit.
Set [MODE SELECTOR 1] to “AUDIO” or “VIDEO”.
Set to the AUDIO side for the CD, TAPE or CD-R/MD position, and
to the VIDEO side for the DVD/VDP, DBS/CABLE, VCR or TV
position.
1
3
Set [MODE SELECTOR 2] to the component you want
to operate.
2
[MODE SELECTOR 2]
[MODE SELECTOR 1]
[
1 ] , [ 2 ] , [ 3 ], [A/B] ,
[ 0 ], [DISC SKIP +] ,
[ 6 7 ],
[
8 9 ] ,
[VCR CH + –]
[SETUP] , [D H F G],
[AUDIO]
, [ENTER] ,
[DISPLAY], [RETURN] ,
[MENU]
[ON/SOURCE]
[OFF]
[SHIFT] [CHANNEL + –]
[NUMBER] (0~9, +10)
[TV/VCR]
[TUNING + – ] ,
[TV VOL. + – ] ,
[ MODE/MENU ] ,
[ BAND/PICTURE ADJUST ] ,
[MEMORY/SUBTITLE]
[SETUP] ,
[D H F G],
[
AUDIO ] ,
[ENTER] ,
[DISPLAY]
,
[ RETURN ]

Denon AVR-887 Specifications

Power

rated output front	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output front alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output center	100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output center alternative	135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output surround	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output surround alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output surround back	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output surround back alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
power supply	AC 120 V, 60 Hz
power consumption	5.5 A

Audio Inputs and Outputs

analog inputs	9 sets
analog ext inputs	8
digital inputs optical	4
digital inputs coaxial	2
audio delay function	0 - 200 msec.
variable subwoofer crossover	40/60/80/90/100/110/120/150/200/250 Hz

Video Inputs and Outputs

component video inputs	3 sets
composite inputs	5
s-video inputs	5
component video outputs	1 set
composite outputs	3
s-video outputs	3

Audio Performance

frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	100 dB (IHF-A weighted)
tone control treble	±6 dB at 10 kHz
tone control bass	±6 dB at 100 Hz

Weight and Dimensions

dimensions	17-3/32” (W) x 6-47/64” (H) x 16-27/64” (D)
dimensions metric	434 (W) x 171 (H) x 417 (D) mm
weight	29 lbs 5 oz
weight metric	13.0 kg
