ENGLISH

Advanced Setup – Part 2 Advanced Setup – Part 2

Setting the Subwoofer Setup

Select the method of playback of the subwoofer for playing the low

bass signals.

Press

DD HH

to select “Subwoofer Setup”, then press

ENTER.

Press

FF GG

to set.

LFE:

For any channel(s) that are set to “Large”, low frequencies in that

channel’s corresponding source are directed to that loudspeaker

only. The low frequencies played from the subwoofer are only the

LFE signals and the low frequencies of channels set to “Small”.

LFE+Main:

Low frequencies from speaker channels that have been set to

“Large” are reproduced from those speakers as well as from the

subwoofer(s).

• The subwoofer mode setting is only valid when and “Yes” is set for

the subwoofer in the “Setting the Speaker Configuration”.

• Select the “LFE+Main” mode if you want low frequency signals to

always be played from the subwoofer channel.

• Select the mode achieving a voluminous bass sound when playing

music or movie sources.

Press ENTER.

Setting the Distance

This parameter is for optimizing the timing with which the audio

signals are produced from the speakers and subwoofer according to

the listening position.

Preparations:

Measure the distances between the listening position and the

speakers (L1 to L8 on the diagram at the below).

Press

DD HH

to select “Distance”, then press ENTER.

C FRFL

Listening position

SL SR

SBL SBR

Press

FF GG

to select “Meters” or “Feet”.

Press

DD HH

to select the speaker, then press

FF GG

to set.

Press ENTER.

•Press

to select “Step”, then press

FF GG

to change the amount of

variation if so desired.

• The distance changes in units of 1 foot (0.1 meters) or 0.1 foot (0.01

meters) each time the button is pressed. Select the value closest to

the measured distance.

• Please note that the difference of distance for every speaker

should be 20 ft (6.0 m) or less. If you set an invalid distance, a

CAUTION notice, such as screen right will appear. In such cases,

move the appropriate speaker to the position of the displayed

value.

..... L1

..... L2

..... L3

..... L4

..... L5

..... L6

..... L7

..... L8

Other manuals for Denon AVR-887

Specifications2 pages

Questions and Answers:

Need help?

Do you have a question about the Denon AVR-887 and is the answer not in the manual?

Denon AVR-887 Specifications

Power

rated output front	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output front alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output center	100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output center alternative	135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output surround	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output surround alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
rated output surround back	100 W + 100 W (8 ohms, 20 Hz - 20 kHz, 0.08 % THD)
rated output surround back alternative	135 W + 135 W (6 ohms, 1 kHz, 0.7 % THD)
power supply	AC 120 V, 60 Hz
power consumption	5.5 A

Audio Inputs and Outputs

analog inputs	9 sets
analog ext inputs	8
digital inputs optical	4
digital inputs coaxial	2
audio delay function	0 - 200 msec.
variable subwoofer crossover	40/60/80/90/100/110/120/150/200/250 Hz

Video Inputs and Outputs

component video inputs	3 sets
composite inputs	5
s-video inputs	5
component video outputs	1 set
composite outputs	3
s-video outputs	3

Audio Performance

frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	100 dB (IHF-A weighted)
tone control treble	±6 dB at 10 kHz
tone control bass	±6 dB at 100 Hz

Weight and Dimensions
