Denon DRA-100 Service Manual

DISASSEMBLY
• Remove each part following the ow below.
• Reassemble the removed parts in the reverse order.
• Read "Precautions During Work" before reassembling the removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing
the work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See "DISASSEMBLY"
3. FRONT PANEL ASSY
and "EXPLODED VIEW"
FRONT PCB
Ref. No. of EXPLODED VIEW : BD2
LED PCB
Ref. No. of EXPLODED VIEW : BD5
USB PCB
Ref. No. of EXPLODED VIEW : BD3
POWER SW PCB
Ref. No. of EXPLODED VIEW : BD8
HP PCB
Ref. No. of EXPLODED VIEW : BD7
TOP COVER
MAIN PCB ASSY
See "DISASSEMBLY"
1. MAIN PCB ASSY
and "EXPLODED VIEW"
MAIN PCB
Ref. No. of EXPLODED VIEW : BD1
BTTOM ASSY
See "DISASSEMBLY"
4. BTTOM ASSY
and "EXPLODED VIEW"
COVER BOTTOM
Ref. No. of EXPLODED VIEW : W6
SMPS PCB
See "DISASSEMBLY"
2. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
Ref. No. of EXPLODED VIEW : BD11
12
