WIRING DIAGRAM
LED
H/P
USB
CN601
(5PIN)
CP102
(3PIN)
TOUCH
NFC
CN221
(3PIN)
CN222
(14PIN)
OLED
CN1002
(14PIN)
CN801
(2PIN)
CN1001
(3PIN)
CN501
(5PIN)
CP301
(4PIN)
CP102
(3PIN)
CN1401
(7PIN)
POWER
CN201
(4PIN)
FPC103
(4PIN)
CN103
(4PIN)
CP102
(3PIN)
FPC101
(31PIN)
VOLUME
SMPS PCB
DENON : DRA-100
CP1901
(5PIN)
FRONT PCB
CN801
(7PIN)
AC_INLET
FPC1201
(31PIN)
CP1305
(5PIN)
DIGITAL IN PCB
WIRING DIAGRAM
MAIN PCB
43
