Dexter Laundry B Series User Manual

16
8514-311-001 REV PR
6 Unit Specifications
T-30 T-50 T-80
Capacity Dry Weight Capacity - lb (kg) 30 (13.6) 50 (22.7) 80 (36.3)
Cylinder Volume - cu ft (L) 11.3 (320) 15.8 (447.4) 23 (651.3)
Speed Tumbler Speed - RPM 47 --- 45 --- 40 ---
Motor Size - hp (kW) 0.5 (0.38) 0.75 (0.56) 0.75 (0.56)
Airflow 8" Outlet - cfm (M3/min) 690 (19.5) 760 (21.5) 1000 (28.3)
Dimensions Cabinet Height - in (cm) 72 1/4 (183.5) 72 1/4 (183.5) 75 3/4 (192.4)
Cabinet Width - in (cm) 31 1/2 (80) 34 1/2 (87.6) 38 1/2 (97.8)
Cabinet Depth - in (cm) 41 3/4 (106) 48 (121.9) 51 3/4 (131.4)
Door Opening - in (cm) 22 5/8 (57.5) 25 5/8 (65.1) 25 5/8 (65.1)
Floor to Door Bottom - in (cm) 28 3/4 (73) 27 1/4 (69.2) 29 1/4 (74.3)
Cylinder Diameter - in (cm) 30 (76.2) 32 1/2 (82.6) 36 1/2 (92.7)
Cylinder Depth - in (cm) 27 1/2 (69.9) 33 (83.8) 38 (96.5)
Lint Screen Area - sq in (sq cm) 515 (3323) 708 (4568) 823 (5310)
Weight Net Weight - lb (kg) 454 (205.9) 540 (244.9) 715 (324.3)
Shipping Shipping Weight - lb (kg) 499 (226.3) 590 (267.6) 770 (349.3)
Shipping Height - in (cm) 77 1/4 (196.2) 77 1/4 (196.2) 80 3/4 (205.1)
Shipping Width - in (cm) 32 3/4 (83.2) 36 (91.4) 40 1/4 (102.2)
Shipping Depth - in (cm) 45 1/2 (115.6) 51 1/2 (130.8) 55 1/2 (141)
Gas Gas Supply Connection - in (mm) 1/2 (12.7) 1/2 (12.7) 3/4 (19.1)
G20 and G25 Supply (Water Column) - in (cm) [kPa] 5-8
(12.7 - 20.3)
[1.25-1.99] 5-8
(12.7 - 20.3)
[1.25-1.99] 5-8
(12.7 - 20.3)
[1.25-1.99]
G20 and G25 Burner Manifold Pressure (Water column) in
(cm) [kPa]
3.4 (8.64) [0.84] 3.5 (8.89) [0.87] 3.5 (8.89) [0.87]
G30 and G31 Gas Supply (Water Column) - in (cm) [kPa]
11 1/2 - 13
1/2
(29.2 - 34.3)
[2.86-3.36]
11 1/2 - 13
1/2
(29.2 - 34.3)
[2.86-3.36]
11 1/2- 13
1/2 (29.2 - 34.3)
G30 and G31 Gas Burner Manifold Pressure (Water column)
in (cm) [kPa]
10 (25.4) [2.50] 9.6 (24.4) [2.40] 10 (25.4) [2.50]
Gas Usage - BTU/hr (kW) [MJ/hr} 74,000 (21.7) [78] 120,000 (35.2) [125] 195,000 (57.1) [204]
Electrical Volts / Hz / Phase / Wiring / Distribution System Circuit Breaker Amps / Running Amps / Wire Size / Reversing
230 / 50 / 1 / 2 wire + ground / TN-S
10 / 5.1 / 2.1 mm2/NON-
REV
10 / 5.1 / 2.1 mm2/NON-
REV
10 / 5.2 / 2.1 mm2/NON-
REV
Installation Minimum Clearance Between Machines - in (cm) 0 0 0 (0) 0 (0)
Minimum Clearance Behind Machines - in (cm) 18 (45.7) 18 (45.7) 18 (45.7)
Make-Up Air Required - sq ft (sq cm) 1 (929) 1.25 (1161) 1.5 (1394)
Exhaust Size - in (cm) 8 (20.3) 8 (20.3) 8 (20.3)
Max. Exhaust Back Pressure (Water Column) - in (mm) 0.3 (7.6) 0.3 (7.6) 0.3 (7.6)
Recommended Exhaust Length - ft (m) & 2 elbows 14 (4.3) 14 (4.3) 14 (4.3)
Table 6-1 Unit Specifications
