50
8514-311-001 REV PR
7.4.3 Temporary Dryer Controller Programming Procedure
1. Make sure the dryer is not in a dry cycle. The 4-digit numeric display on the dryer
controller will show “LOAd” when the dryer is not in a dry cycle.
2. Press and release the UP or DOWN touch pad switch on the dryer controller to choose the
dry cycle that you want to change (dry cycle 1 through 5). The dry cycle L.E.D. will illuminate
to indicate which dry cycle you are choosing. If you press and hold down either the UP or
DOWN touch pad switch, the controller will sequence through the five dry cycles.
3. Press and release the CYCLE touch pad switch on the dryer controller once you have
chosen the dry cycle you want to change. After you press the CYCLE touch pad switch, the
programming L.E.D. and the dry time L.E.D. will illuminate, the dry cycle L.E.D. will remain
illuminated, and the total dry time will be displayed on the 4-digit numeric display.
4. Press and release the UP or DOWN touch pad switch on the dryer controller to change the
total cycle time. Once either the UP or DOWN touch pad switch is pressed, the dry time
L.E.D. and the total dry time on the 4-digit numeric display will flash. If you press and hold
down either the UP or DOWN touch pad switch, you will increment (UP arrow) or
decrement (DOWN arrow) through the total dry times available (1 through 60 minutes).
This display dry time includes the cool down time along with the heated time. To not
change the cool down time, do not press either the UP or DOWN touch pad switch. Go
to the next step.
5. Press and release the SELECT/ENTER touch pad switch on the dryer controller. Once
the SELECT/ENTER touch pad switch is pressed and released, the dry time L.E.D. will
switch off, the dry cycle L.E.D. and programming L.E.D. will remain on, the temperature
L.E.D. will illuminate, and the drying temperature will be shown on the 4-digit numeric
display.
6. Press and release either the UP or DOWN touch pad switch on the dryer controller to change
the drying temperature. Each press and release of either the UP or DOWN touch pad
switch will either increase or decrease, respectively, the temperature by five degrees
Fahrenheit or three degrees Celsius, depending on how your dryer controller is set up.
Once either the UP or DOWN touch pad switch is pressed, the temperature L.E.D. and
the drying temperature on the 4-digit numeric display will flash. If you press and hold
down either the UP or DOWN touch pad switch, you will increment (UP arrow) or
decrement (DOWN arrow) your way through the available drying temperatures (105°
Fahrenheit or 41° Celsius, up to 195° Fahrenheit or 90° Celsius). If you do not want to
change the drying temperature, do not press either the UP or DOWN touch pad switch. Go
to the next step
7. Press and release the SELECT/ENTER touch pad switch on the dryer controller. Once the
SELECT/ENTER touch pad switch is pressed and released, the temperature L.E.D. will
switch off, the dry cycle L.E.D. and programming L.E.D. will remain on, the cool down L.E.D.
will illuminate, and the cool down time will be shown on the 4-digit numeric display.
