21
8514-311-001 REV PR
3. With a walking motion move dryer completely off crate base. Save the crate base for
use if the dryer is ever moved again.
4. Slide unit into position where it will be installed. Adjust leveling legs, using the groove joint
pliers, to level and align dryer with adjacent units.
INFORMATION
If the dryer is ever moved again, the
dryer should be re-mounted on its crate
base and its crating bolts re-inserted and
tightened, in the reverse order as above.
7.1.2 Code Conformity
This appliance must be installed in accordance with the rules in force and used only in a
sufficiently ventilated space. Consult instructions before installation of this appliance.
All industrial dryer installations must conform with local and national codes for the location of
installation and ventilation requirements.
The appliance must not be installed behind a lockable door, a sliding door or a door with a
hinge on the opposite side to that of the tumble dryer, in such a way that a full opening of the
tumble dryer door is restricted.
7.1.3 Installation Clearances
This unit may be installed at the following alcove clearances:
Left Side 0 mm (0 inches)
Right Side 0 mm (0 inches)
Back 457 mm (18 inches) Certified for 25 mm (1 inch) clearance; however, 457
mm (18 inches) clearance is necessary behind the motors to allow
servicing and maintenance.
Front 1220 mm (48 inches) to allow use of dryer.
Top Refer to the figure below labeled “Vertical Clearance Dimensions”.
Dimensions A and B in Figure 7-1. Certification allows 0 mm (0 inches)
clearance for wall framing at the top up to 457 mm (18 inches) back
from the front.
Dimension C in Figure 7-1. However, a 6 mm (¼ inches) clearance
should be allowed so that the upper door can be opened.
Floor This unit may be installed upon a combustible floor.
Do not obstruct the flow of combustion and ventilation air.
Maintain minimum of 25 mm (1 inch) clearance between duct and combustible material.
Refer to the label attached to the Belt Guard on the rear of the dryer for other installation
information and start-up instructions.
