XBee/XBee-PRO
®
DigiMesh 2.4 User Manual
Explicit Addressing Command Frame
Frame Type: 0x11
Allows application layer fields (endpoint and cluster ID) to be specified for a data transmission.
Similar to the Transmit Request, but also requires application layer addressing fields to be
specified (endpoints, cluster ID, profile ID). An Explicit Addressing Request API frame causes the
module to send data as an RF packet to the specified destination, using the specified source and
destination endpoints, cluster ID, and profile ID.
The 64-bit destination address should be set to 0x000000000000FFFF for a broadcast
transmission (to all devices). For unicast transmissions the 64 bit address field should be set to
the address of the desired destination node. The reserved field should be set to 0xFFFE. The
broadcast radius can be set from 0 up to NH to 0xFF. If the broadcast radius exceeds the value
of NH then the value of NH will be used as the radius. This parameter is only used for broadcast
transmissions. The maximum number of payload bytes can be read with the NP command.
Frame Fields Offset Example Description
Start Delimiter 0 0x7E
Length
MSB 1 0x00
Number of bytes between the length
and the checksum
LSB 2 0x1A
