© 2014 Digi International Inc. 78
XBee/XBee-PRO
®
DigiMesh 2.4 User Manual
Remote AT Command Request
Frame Type: 0x17
Used to query or set module parameters on a remote device. For parameter changes on the
remote device to take effect, changes must be applied, either by setting the apply changes
options bit, or by sending an AC command to the remote.
Example. The above example sends a remote command to change the broadcast hops register
on a remote device to 1 (broadcasts go to 1-hop neighbors only), and apply changes so the new
configuration value immediately takes effect. In this example, the 64-bit address of the remote is
0x0013A200 40401122.
Frame Fields Offset Example Description
Start Delimiter 0 0x7E
Length
MSB 1 0x00
Number of bytes between the length
and the checksum
LSB 2 0x10
Frame-specific
Data
Frame Type 3 0x17
Frame ID 4 0x01
Identifies the UART data frame for
the host to correlate with a
subsequent ACK (acknowledgement).
If set to 0, no response is sent.
64-bit
Destination
Address
MSB 5 0x00
Set to the 64-bit address of the
destination device. The following
address is also supported:
0x000000000000FFFF - Broadcast
address
60x13
70xA2
80x00
90x40
10 0x40
11 0x11
LSB 12 0x22
Reserved
13 0xFF
Set to 0xFFFE.
14 0xFE
Remote
Command
Options
15
0x02 (apply
changes)
0x02 - Apply changes on remote. (If
not set, AC command must be sent
before changes will take effect.)
All other bits must be set to 0.
AT Command
16 0x42 (B)
Name of the command
17 0x48 (H)
Command
Parameter
18 0x01
If present, indicates the requested
parameter value to set the given
register. If no characters present,
the register is queried.
Checksum 18 0xF5
0xFF - the 8 bit sum of bytes from
offset 3 to this byte.
