Eaton EFX48 e-Fuse Series User Manual

Appendix A
Connector Pin-outs


Copyright © 2019 Eaton Corporation. All Rights Reserved.
IPN March 2019
151
Append ix A
EFX48 Controller Menu
Append ix B
Connector Pin-outs
EFX48 System Controller Connector Pin-outs
Connector Type Purpose Pin Description
RJ45 Ethernet Interface 1 Tx+
2 Tx-
3 Rx+
4 -
5 -
6 Rx-
7 -
8 -
GPIO 14 way 2.5mm
pitch screwless
terminal
General purpose digital I/O
Relays
Mid-point monitoring
Analog inputs
1 GPIO1
2 GPIO2
3 GPIO3
4 DIN/AIN4
5 DIN/AIN5
6 GND
7 RLY1_N/O
8 RLY2_N/O
9 RLY3_N/O
10 RLY123_COM
11 RLY4_NO
12 RLY4_COM
13 RLY5_NO
14 RLY5_COM
BATT SENSE 2way DF14A Battery temperature sensor Eaton
Part No. tba
1 BATT_TEMP+
2 BATT_TEMP-
STRINGS 4way 10mm
pitch screwless
terminal
Battery string connections 1 STRING1+
2 STRING1-
3 STRING2+
4 STRING2-
LOADS 12way 5mm
pitch terminal
Load connections 1 LOAD1+
2 LOAD1-
