For more information visit: www.cutler-hammer.eaton.com
Page 13 -9
Effective 10/02 IL17562BH04
13.6 Drawout Operation
13.6.1 Inserting the Relay
Before the MP-3000 is inserted into the Drawout Outer Case:
• Verify that all wiring is correct as shown in the wiring diagram.
• Set the INCOM communication device address.
• If the URTD fiber optic cable is used refer to Section 13.4.1 for
special instructions concerning the proper installation of the fiber.
When inserting the MP-3000 inner chassis into the drawout outer
case, use the guides to align the exterior of the inner chassis with the
interior of the outer case. Slide the unit into the Case using the
guides, pressing firmly until all four latches located on the sides of the
device are seated and latched into place. Tabs on the MP-3000
Drawout Inner Chassis will prevent the inner chassis from being
inserted upside down or being inserted into an outer case of another
relay or IQ metering product.
CAUTION
THE MP-3000 INNER CHASSIS MUST BE FULLY INSERTED AND
FULLY LATCHED IN TO ITS DRAWOUT OUTER CASE FOR
PROPER OPERATION OF THE DEVICE.
When the unit is seated properly, the quick release buttons at the top
and bottom of the unit will return to their non-compressed position.
The device can now be secured in the outer case by inserting a
locking ring or meter seal in the provided slot.
13.6.2 Removing the Relay
WARNING
REMOVAL OF THE MP-3000 INNER CHASSIS FROM THE
DRAWOUT OUTER CASE EXPOSES LIVE PARTS, WHERE THE
HAZARD OF A FATAL ELECTRIC SHOCK IS PRESENT. ALWAYS
DISCONNECT ANY CONTROL OR SOURCE POWER BEFORE
TOUCHING ANYTHING ON THE INTERNAL OR EXTERNAL PARTS
OF THE DRAWOUT OUTER CASE.
When removing the Inner Chassis from the Drawout Outer Case, first
remove any locking ring that has been installed. Press the top and
bottom quick release buttons simultaneously, and pull the relay out by
its front panel.
NOTE: If the URTD fiber cable is used, refer to Section 13.4.2 for
proper removal of the relay to prevent damage to the fiber optics.
13.7 Warranty and Liability Information
NO WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE OF
MERCHANTABILITY, OR WARRANTIES ARISING FROM COURSE
OF DEALING OR USAGE OF TRADE ARE MADE REGARDING THE
INFORMATION, RECOMMENDATIONS, AND DESCRIPTIONS
CONTAINED HEREIN. In no event will Cutler-Hammer be responsible
to the purchaser or user in contract, in tort (including negligence),
strict liability, otherwise for any special, indirect, incidental, or
consequential damage or loss whatsoever, including but not limited to
damage or loss of use of equipment, plant or power system, cost of
capital, loss of power, additional expenses in the use of existing power
facilities, or claims against the purchaser or user by its customers
resulting from the use of the information and descriptions contained
herein.
13.8 Technical Assistance
For additional information, technical assistance, or referral to a local
authorized distributor, contact Power Management Applications
Support at 1-800-809-2772 option 1/option 1 or www.cutler-
hammer.eaton.com and follow the power management products link.
