Eaton MP-3000 User Manual

Page 11-2
Effective 10/02For more information visit: www.cutler-hammer.eaton.comIL17562BH04
11.10 Checking Discrete Input 1
Use P13L7 to see if discrete input 1 is either on or off. Apply or
remove 120 Vac to check both states.
11.11 Checking Discrete Input 2
Use P13L8 to see if discrete input 2 is either on or off. Apply or
remove 120 Vac to check both states.

Eaton MP-3000 Specifications

General

Brand	Eaton
Model	MP-3000
Category	Relays
Language	English
