Effective 10/02
Page 4-4Page 4-4
For more information visit: www.cutler-hammer.eaton.comIL17562BH04
Page Line Complete Help Message Description
MONITOR MONITOR OF REAL TIME VALUES Monitor mode
MONT I REAL TIME DATA FROM CURRENT Current monitoring data follows
MEASUREMENTS
IAVG XXX AVERAGE OF THREE PHASE CURRENT Average rms current of 3-phase currents in
amps
IA XXX PHASE A CURRENT IN AMPS Actual ac line motor rms current
IB XXX PHASE B CURRENT IN AMPS
IC XXX PHASE C CURRENT IN AMPS
IG XXX GROUND FAULT CURRENT IN AMPS Actual ground current
%IA XXX PHASE A CURRENT AS A PERCENT OF The percents of the actual
FULL LOAD AMPS
%IB XXX PHASE B CURRENT AS A PERCENT OF monitored current in amps
FULL LOAD AMPS
%IC XXX PHASE C CURRENT AS A PERCENT OF
FULL LOAD AMPS
%UB XXX PHASE UNBALANCE – IF POSITIVE THE Ratio of negative sequence current to positive
RATIO OF NEGATIVE TO POSITIVE sequence current in percent. If a phase reversal
SEQUENCE CURRENT – IF NEGATIVE exists, then the ratio is inverted and a negative
THE INVERSE sign is displayed.
MONT RTD REAL TIME DATA FROM RTD MODULE RTD monitoring data follows. Page is only
visible when an URTD is communicating with the
MP-3000
WT1 XXXX WINDING TEMP 1 IN DEGREES F (or) C RTD reading – terminals 1,2,3
WT2 XXXX WINDING TEMP 2 IN DEGREES F (or) C RTD reading – terminals 4,5,6
WT3 XXXX WINDING TEMP 3 IN DEGREES F (or) C RTD reading – terminals 7,8,9
WT4 XXXX WINDING TEMP 4 IN DEGREES F (or) C RTD reading – terminals 10,11,12
WT5 XXXX WINDING TEMP 5 IN DEGREES F (or) C RTD reading – terminals 13,14,15
WT6 XXXX WINDING TEMP 6 IN DEGREES F (or) C RTD reading – terminals 17,18,19
MT1 XXXX MOTOR BEARING TEMP 1 IN RTD reading – terminals 20,21,22
DEGREES F (or) C
MT2 XXXX MOTOR BEARING TEMP 2 IN RTD reading – terminals 23,24,25
DEGREES F (or) C
LT1 XXXX LOAD BEARING TEMP 1 IN RTD reading – terminals 26,27,28
DEGREES F (or) C
LT2 XXXX LOAD BEARING TEMP 2 IN RTD reading – terminals 29,30,31
DEGREES F (or) C
AXT XXXX AUXILIARY TEMP IN DEGREES F (or) C RTD reading – terminals 33,34,35
MONT MTR REAL TIME MOTOR DATA Motor monitoring data follows
VER XXXX SOFTWARE VERSION NUMBER MP-3000 software version in use
%I2T XXX PERCENT OF I2T TRIP LEVEL Percent of thermal bucket used
TUS XXX TIME IN MINUTES UNTIL NEXT START Displays largest amount of time in minutes
CAN OCCUR among three functions: anti-backspin, starts per
unit time, and time between starts.
RMST XX REMAINING STARTS Number of starts remaining if starts per time is
programmed.
Table 4.2 Monitor Mode Display
