Eaton MP-3000 User Manual

Effective 10/02
Page 4-19
For more information visit: www.cutler-hammer.eaton.com
Page 4-19
IL17562BH04
Selected
Value
Line
No.
3
4
Display
ALRM RST
or
PUSH RST
TOT RST
or
PUSH RST
Help Message
ALRM RST – PUSH RAISE TO ENABLE
ALARM HISTORY RESET
PUSH RST – PUSH RESET TO EXECUTE
RESET OF ALARM HISTORY OR PUSH
RAISE TO NOT RESET
TOT RST - PUSH RAISE TO ENABLE
TOTAL HISTORY RESET
PUSH RST - PUSH RESET TO EXECUTE
RESET OF ALARM HISTORY OR PUSH
RAISE TO NOT RESET
Setting
Range/ Value
Selection
Change to PUSH
RST and press
Reset button, or
return to ALRM
RST
Change to PUSH
RST and press
Reset button, or
return to TOT RST
Value
as
shipped
—
—
Section
Reference
5.14.3
5.14.4
Table 4.4 History Mode Display
Note: For any of the Line functions, the Value buttons are used to view the multiple displays.
Display
OCNT XX
MM/DD/YY
HH:MM:SS
RT XXXX
MM/DD/YY
HH:MM:SS
IMS XXXX
MM/DD/YY
HH:MM:SS
IMR XXXX
MM/DD/YY
HH:MM:SS
UBM XXX
MM/DD/YY
HH:MM:SS
WMX XXXX
MM/DD/YY
HH:MM:SS
MBX XXXX
MM/DD/YY
HH:MM:SS
LMX XXXX
MM/DD/YY
HH:MM:SS
Complete Help Message
HISTORY MODE
HISTORY OF MOTOR STATISTICS
OPERATION COUNT SINCE LAST
RESET
DATE OF RESET
TIME OF RESET
RUN TIME HOURS SINCE LAST
RESET
DATE OF RESET
TIME OF RESET
HIGHEST STARTING PHASE
CURRENT
DATE OF EVENT
TIME OF EVENT
HIGHEST RUNNING PHASE CURRENT
DATE OF EVENT
TIME OF EVENT
HIGHEST PHASE UNBALANCE
DATE OF EVENT
TIME OF EVENT
HIGHEST MOTOR WINDING
TEMPERATURE IN DEGREES C(F)
DATE OF EVENT
TIME OF EVENT
HIGHEST MOTOR BEARING
TEMPERATURE IN DEGREES C(F)
DATE OF EVENT
TIME OF EVENT
HIGHEST LOAD BEARING
TEMPERATURE IN DEGREES C(F)
DATE OF EVENT
TIME OF EVENT
Page
HISTORY
HIST MTR
Line
OCNT XX
RT XXXX
IMS XXXX
IMR XXXX
UBM XXX
WMX XXXX
MBX XXXX
LMX XXXX
Description
Recalls stored motor data
This page contains historical informa-
tion of motor since reset
The number of motor starts logged
since last reset
The date when OCNT was reset
The time when OCNT was reset
Total motor run time accumulated
since last reset
The date when RT was reset
The time when RT was reset
Highest starting phase current
monitored since last reset
The date of highest IMS
The time of highest IMS
Highest running phase current
monitored since last reset
The date of highest IMR
The time of highest IMR
Maximum phase unbalance monitored
since last reset
Date of highest phase unbalance
Time of highest phase unbalance
Maximum motor winding temperature
monitored since reset
The date of highest WMX
The time of highest WMX
Maximum motor bearing temperature
monitored since reset
The date of highest MBX
The time of highest MBX
Maximum load bearing temperature
monitored since reset
The date of highest LMX
The time of highest LMX
