Water Tanks
Next Generation Side by Sides may have either a Water
Tank Assembly or a Water Tube Assembly as shown in
Figure H4.
Water Tube
Assembly
To Filter
Figure H4
The water line from the primary water valve (single coil
valve) goes behind the trim located on the right side of the
inside food compartment liner to the water filter. From the
water filter the line goes to the water tank, then to the
secondary water valve (two coil valve). The two coil valve
dispenses water to the ice maker and to the dispenser in
the door. Filling the ice maker from the water tank will get
chilled water to the ice maker and help increase ice
production. See Figures H5, H6 and H7 for water system
flow diagrams.
Figure H5
Front Filter System
