Envoy Installation and Operation
2014 Enphase Energy Inc. 141-00011 Rev 05
Viewing the Grid Configuration
To view the grid configuration (trip points profile) for the site, do the following.
NOTE: You cannot change the grid profile using this menu. To change this profile, and for
more information on grid profiles, see “Set or Change the Grid Profile” on page 41.
1. Press and hold the Envoy Menu button. After two seconds the Envoy menu appears.
2. Continue holding the Menu button. When the LCD screen displays View Grid Configuration,
release the Menu button.
The LCD screen then reads:
If a grid profile has not been applied, the following screen is displayed.
This indicates that the microinverters are using the factory-installed (default) grid profile.
3. If needed, select a profile as described in “Set or Change the Grid Profile” on page 41.
If a grid profile has been applied, the following screens may be displayed.
4. Press the menu button at any time to exit this process.
Number of microinverters detected.
Number of microinverters that cannot be
set with a grid profile.
Number of microinverters that are set
with a grid profile and the name of the
specification being used.
(n)devices are set
with (local spec)
Using factory-inst’d
grid profile
Gathering Grid
Configuration Data
To Next Page
