Installing and Connecting a Redundant Power System
2-22 Installation
Required Tools
A flat-blade screwdriver is required to install the STK-RPS-150CH2 or STK-RPS-150CH8 shelf and
08A-RPS-150P power supplies.
Unpacking the Shelf and Power Supply
The shelf and the power supply are shipped separately. To unpack these devices proceed as
follows:
1. Open the box and remove the packing material protecting the shelf or power supply.
2. Verify the contents of each carton and compare the contents shipped with those listed in
Table 2-1, Table 2-2, and Table 2-3.
3. Perform a visual inspection of the components for any signs of physical damage. Contact
Enterasys Networks if there are any signs of damage. Refer to “Getting Help” on page xvii for
details.
Installing an 08A-RPS-150P Into a Shelf
If you are using the 08A-RPS-150P as a standalone unit, go to “Connecting the RPS Cable and AC
Power Cord” on page 2-27.
When you receive your STK-RPS-150CH8 shelf, a coverplate will be in place over each
power-supply slot.
To install the power supplies, refer to Figure 2-17 or Figure 2-18 and proceed as follows:
1. Place the chassis on a sturdy flat surface where you plan to install power supplies.
Table 2-1 Contents of STK-RPS-150CH2 Carton
Item Quantity
STK-RPS-150CH2 1
Quick Reference 1
Table 2-2 Contents of STK-RPS-150CH8 Carton
Item Quantity
STK-RPS-150CH8 1
Quick Reference 1
Table 2-3 Contents of 08A-RPS-150P Carton
Item Quantity
08A-RPS-150P 150 watt DC power supply 1
USA, NEMA power cord 1
RPS cable (1 meter in length) 1
Notice card 1
Caution: Observe all Electrostatic Discharge (ESD) precautions when handling sensitive electronic
equipment.
Precaución: Al trabajar con equipos electrónicos sensibles, tome todas las precauciones de
seguridad para evitar descargas de electricidad estática.
