Epson PowerLite S4 User Manual

3
Contents
Meaning of Symbols 2
Copyright Notice 2
Trademarks 2
Projector Features
Setting Up the Projector 6
Part Names and Functions 7
Front/Top 7
Control Panel 8
Rear 9
Base 10
Remote Control 11
Adjusting and Changing the Image
Adjusting the Image Quality 12
Adjusting Computer Images and RGB Video Images 12
Selecting the Projection Quality (Color Mode) 14
Adjusting the Projection Position (Image Shift) 16
Adjusting the Volume 17
Selecting the Image Source 17
Automatically Detecting the Source (Source Search) 17
Selecting the Source from the Remote Control 18
Additional Projector Functions
Functions for Enhancing Projection 19
Muting the Image and Sound (A/V Mute) 19
Freezing the Image 20
Changing the Aspect Ratio 20
Displaying the Pointer 21
Enlarging Part of the Image (E-Zoom) 21
Using the Remote Control as a Mouse 22
Security Functions 24
Preventing theft (Password Protect) 24
Using the Operation Lock 26
Saving a User's Logo 28
Displaying Projected Images on an External Monitor 30
Configuration Menus
Using the Menu System 31
"Image" Menu 32
"Signal" Menu 33
"Settings" Menu 34
"Extended" Menu 35
"Info" Menu 37
"Reset" Menu 38

Epson PowerLite S4 Specifications

General

Number of colors	16.78 million colors
Projection distance	6 m
Vertical scan range	48 - 85 Hz
Horizontal scan range	15 - 92 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	30 - 300 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	16.6 mm
Interface	USB
Audio input	RCA x 2
Dimensions (WxDxH)	246 x 328 x 100 mm
Power requirements	100-240 V +/- 10%, 50/60 Hz AC
Connectivity technology	Wired
Noise level	36 dB
Dot clock scanning frequency	162 MHz
RMS rated power	1 W
Number of built-in speakers	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	5 W
Power consumption (typical)	250 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	2600 g
