List of ESC/VP21 Commands
List of ESC/VP21 Commands
Command List
When a power on command is sent to the projector, the power will turn on and
the projector will change to warm-up mode. When the power has turned on, a
colon ":" (3Ah) will be returned.
When the projector executes a command, it returns a ":" and waits for the next
command to be sent.
If command processing terminates with an error, the projector outputs an
error message and then returns the ":" code.
* When issuing any of the above commands, tack a Carriage Return (CR) code (0Dh)
on to the end.
Cable Layouts
Connector shape: USB (type B)
Item Command
Power ON/OFF On PWR ON
Off PWR OFF
Signal selection Computer (Auto) SOURCE 1F
Computer1 SOURCE 11
Component Video SOURCE 14
Video SOURCE 41
S-Video SOURCE 42
A/V Mute ON/OFF On MUTE ON
Off MUTE OFF
A/V Mute Selection Black MSEL 00
Blue MSEL 01
User’s Logo MSEL 02
USB connection
<At the projector
>
<At the computer
>
(type B)
To Next Page
