Epson PowerLite S4 User Manual

64
Specifications
Specifications
* The USB interface complies with the USB 1.1 standard. The USB connector is not
guaranteed to operate correctly with all USB-compatible devices.
Angle of tilt
If you use the projector when it is tilted more than 30°, it could fall or be
damaged.
Dimensions 15.3 (W) × 6.5 (H) × 13.9 (D) inches
327 (W) × 87 (H) × 247 (D) mm (not including feet)
Display method Polysilicon TFT active matrix
Resolution SVGA 480,000 pixels (800 (W) × 600 (H) dots) × 3
Contrast ratio 500:1
Brightness 1800 ANSI lumens (high brightness)
1500 ANSI lumens (low brightness)
Focus adjustment Manual
Zoom adjustment Electronic (approx. 1:1.35)
Lamp UHE lamp, 170 W
Lamp life 2000 hours (high brightness)
3000 hours (low brightness)
Speaker 1W monaural
Power supply 100/240VAC 50/60Hz 2.2/1.0A
Power consumption Operating: 250W (100 to 120V area)
240W (220 to 240V area)
Standby:5W (100 to 120V area)
6W (220 to 240V area)
Operating altitude 0 to 2,286 m (0 to 7,500 ft)
Operating
temperature
+5 to +35ºC (41 to 95ºF) (No condensation)
Storage temperature -10 to +60ºC (14 to 140ºF) (No condensation)
Weight Approx. 2.6 kg (5.7 lb)
Fan noise 36 db (high brightness)
30 db (low brightness)
Connectors Computer 1 Mini D-Sub 15-pin (female)
Blue
S-Video 1 Mini DIN 4-pin
Video 1 RCA pin jack
Audio Input 1 RCA pin jack×2 (L,R)
USB* 1 USB connector (B series)
Monitor Out 1 Mini D-Sub 15-pin (female)
Black
p
Lamp life results vary depending on mode selected, environmental
conditions, and usage. Lamp brightness decreases over time. Turn off this
product when not in use to prolong the life of the projector.
Pixelworks DNX
TM
ICs are used in this Projector.
0°- 30° 0°- 30°

Epson PowerLite S4 Specifications

General

Number of colors	16.78 million colors
Projection distance	6 m
Vertical scan range	48 - 85 Hz
Horizontal scan range	15 - 92 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	30 - 300 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	16.6 mm
Interface	USB
Audio input	RCA x 2
Dimensions (WxDxH)	246 x 328 x 100 mm
Power requirements	100-240 V +/- 10%, 50/60 Hz AC
Connectivity technology	Wired
Noise level	36 dB
Dot clock scanning frequency	162 MHz
RMS rated power	1 W
Number of built-in speakers	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	5 W
Power consumption (typical)	250 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	2600 g
