Epson PowerLite S4 User Manual

7
Part Names and Functions
Part Names and Functions
Front/Top
Lamp cover
Open this cover when replacing the
projector's lamp.
Control panel
Remote control light-receiving area
Receives signals from the remote control.
Front adjustable foot
Raises the projector to adjust the projection
angle.
Lens cover
Slide shut when not using the projector to
protect the lens.
If you close it while projecting, the image and
sound are termporarily stopped.
Focus ring
Adjusts the image focus.
Foot release lever
Extends the front foot.
Air exhaust vent
Security lock

Epson PowerLite S4 Specifications

General

Number of colors	16.78 million colors
Projection distance	6 m
Vertical scan range	48 - 85 Hz
Horizontal scan range	15 - 92 kHz
Projection technology	LCD
Contrast ratio (typical)	500:1
Screen size compatibility	30 - 300 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-30 - 30 °
Lamp type	UHE
Lamp power	170 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	16.6 mm
Interface	USB
Audio input	RCA x 2
Dimensions (WxDxH)	246 x 328 x 100 mm
Power requirements	100-240 V +/- 10%, 50/60 Hz AC
Connectivity technology	Wired
Noise level	36 dB
Dot clock scanning frequency	162 MHz
RMS rated power	1 W
Number of built-in speakers	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (standby)	5 W
Power consumption (typical)	250 W
Operating temperature (T-T)	5 - 35 °C

Weight and Dimensions

Weight	2600 g
