Appendix Fatal Error Code 81
SC-P600 Revision D
4.3 Fatal Error Code
This section describes the fatal error code and the possible cause for this product.
Table 4-2. Fatal Error List
Error
type
Error
code
Error name Possible cause Suspect Parts
DC motor
error (CR)
01H PID excess load error
• CR Encoder failure
• Motor driver failure
• Increase of CR load when printer is
printing (CR shaft is damaged, CR shaft
receiver is damaged, Grease is
consumed, DR layshaft is deformed)
• Paper jam
• CR is collided to Front Tray Assy
• CR is collided to Upper Paper Guide
Assy
• CR Motor failure
• CR Encoder
• CR FFC
• Main Board
• CR Shaft, CR Unit, Guide CR
• CR grease
• Remove Paper Jam
• Front Tray Assy
• Front Tray Sensor
•APG Assy
• Upper Paper Guide Assy
• CR Motor
03H PID reverse error
• CR Scale stain
• CR Encoder failure
• Motor driver failure
• CR Belt failure
• CR Pully failure
• CR Scale
• CR Encoder Assy
• CR FFC
• Main Board
• CR Belt
• CR Pully
05H PID speed degradation error
• CR Encoder failure
• Motor driver
• CR Encoder
• CR FFC
• Main Board
• CR Motor
• Paper Jam
DC motor
error (PF)
F1H PID excess load error
• PF Encoder failure
• Motor driver failure
• Increase of PF load (CR Bush is weared,
CR grease is consumed, PF Roller
Center Support is deformed, CR is
collided to Front Tray Assy)
• Paper jam
• PF Motor failure
• PF Encoder
• Main Board
• Check PF Belt tension
• CR Shaft grease
• Check PF Roller Shaft Center Support
Position Adjustment
• PF Roller
• PF Encoder
• Paper Jam
• PF Motor
• Front Tray Assy
• Rear Guide Assy
F3H PID reverse error
• PF Scale stain
• PF Encoder failure
• Motor driver failure
• PF Belt failure
• PF Scale
• PF Encoder
• PF Encoder FFC
• Main Board
• PF Belt
F6H
Over current error
• Connection failure of the PF Motor or
the PF Encoder.
• PF irregular load
• PF Motor or PF Encoder failure.
• PF Encoder
• PF Motor
To Next Page
