SE Group Confidential (Related Staff Only)
Disassembly/Reassembly Overview 9
SC-P600 Revision D
1.1 Overview
This chapter describes procedures for disassembling the main parts/units of Stylus Photo R3000. Unless
otherwise specified, disassembled parts/units can be reassembled by reversing the disassembly procedure. See
the cautions or tips for disassembly/reassembly described in "1.3 Detailed Disassembly/Reassembly Procedure
for each Part/Unit (p19)".
Read the "Safety Precautions (p3)" before disassembling and reassembling.
When you have to remove units or parts that are not described in this chapter, see the exploded diagrams of SPI
(Service Parts Information).
1.1.1 Tools
Use only specified tools to avoid damaging the printer.
Note *1: Some of the tools listed above are commercially available.
*2: EPSON provides the tools listed with EPSON part code.
This warning is for Taiwan.
Name Availability
*1
EPSON Part Code
*2
(+) Phillips screwdriver #1 O 1080530
(+) Phillips screwdriver #2 O ---
Flathead screwdriver O ---
Flathead Precision screwdriver #1 O ---
Tweezers O ---
Longnose pliers O ---
Acetate tape --- 1003963
Nippers O ---
Bring back the following brought and used items, then dispose of them based on the local
regulations in your country, please.
Ink cartridges
Cleaning cartridges
Draining cartridges
Especially in case of ink cartridges in Europe, please refer to the following web site to
confirm the regulation in detail.
ECO Info: http://www.epson.eu/weee (available from July 2015)
To Next Page
