Epson Stylus C67 Service Manual

EPSON Stylus C67/C68/D68 Revision A
APPENDIX Parts List 102
7.2 Parts List
 Parts list for the EPSON Stylus C67/C68/D68
Ref No. Part Name
100 HOUSING, UPPER; EDG2
101 COVER, INK TUBE; EDG2
102 COVER, I/F; EDG2
103 STACKER ASSY.
104 PAPER SUPPORT ASSY.; EFS3
105 COVER, PRINTER; EFS3; C67
106 BUTTON, SW ASSY., A
200 BOARD ASSY., MAIN
300 POWER SUPPLY ASSY.
400 POWER CABLE
500 PRINTER MECHANISM(ASP)MAD13-100
501 FOOT
502 POROUS PAD, INK EJECT, UPPER, LARGE
503 POROUS PAD, INK EJECT, LOWER, BIG; D
504 POROUS PAD, INK EJECT, FB
505 INSULATOR, FRAME, MAIN
507 ROLLER, EJECT
508 INKSYSTEM ASSY.
509 PAPER GUIDE, FRONT ASSY.
510 POROUS PAD, INK EJECT, LOWER, SMALL
511 PROUS PAD, CAP, LOWER, SMALL
512 POROUS PAD, TUBE, FASTEN
513 HOLDER, SHAFT ASSY.; B
514 FRAME, FRONT ASSY.
515 POROUS PAD, PAPER GUIDE FRONT, LOWER
541 SHEET, POROUS PAD, COVER
542 DIFFUSION SHEET, INK EJECT, LOWER, ASP
700 PRINT HEAD ASSY.
701 SCALE, CR
702 ASF UNIT
703 GROUNDING PLATE, HEAD
704 TORSION SPRING, LEVER, CARTRIDGE
706 SHIELD PLATE, CABLE HEAD ASSY., C616
707 BOARD ASSY., ENCODER
708 BOARD ASSY., PANEL
709 LABEL, POSITION, CARTRIDGE
710 LEVER, CARTRIDGE
711 HOLDER, I/C ASSY.
714 PLATE, SLIDER
716 TIMING BELT; E
NON FIG INK CART.UNBOXED, BK-SS, PIG'T; G38K, A/A, AS
NON FIG INK CART.UNBOXED, C-SS, PIG'T; G38K, A/A, AS
NON FIG INK CART.UNBOXED, M-SS, PIG'T; G38K, A/A, AS
NON FIG INK CART.UNBOXED, Y-SS, PIG'T; G38K, A/A, AS
NON FIG INTERFACE CABLE; USB2.0
NON FIG SOFTWARE CD, EAI-LATIN
NON FIG USER'S GUIDE
NON FIG USER'S GUIDE
NON FIG SETTING UP MANUAL
