EPSON Stylus C67/C68/D68 Revision A
ADJUSTMENT Adjustment by Using Adjustment Program 82
5.2 Adjustment by Using Adjustment Program
The procedures of the adjustment items will be explained here. The intended item is
as follows.
 Market setting
 USB ID input
 Head ID input
 Head angular adjustment
 Bi-d adjustment
 PF adjustment
 First dot adjustment
 Top margin adjustment
 Offset input for CR motor calorific limitation
 A4 Normal Paper print
 A4 Photo Quality Inkjet Paper print
 PF torque check pattern print
5.2.1 Market ID Setting
[Adjustment Procedure]
1. Select the Market ID of the adjustment program.
2. Click the [OK] button to write the specific data into EEPROM.
3. Click the [Check] button to check market and model name.
5.2.2 USB ID Input
[Adjustment Procedure]
1. Select USB ID input in the adjustment program.
2. Enter the 10-digits serial number from the label applied to the bottom side of the
Upper housing.
5.2.3 Head ID Input
[Adjustment Procedure]
1. Select the Head ID of the adjustment program.
2. Enter the 16-digits code of the Head ID label applied to the Printhead. Enter the
Head ID from left to right on the top row and from top to bottom in due order.
