EPSON
TITLE
SHEET
REVISION
NO.
SHEETNEXT
F
TM-U295/U295P
Specification
(STANDARD)
22 21
3.3 Buttons and Switches
3.3.1 Panel buttons
The
ESC c 5
command enables the panel buttons. When disabled, none of the buttons will not
function.
1) Release button (RELEASE) (Non-locking push button)
Function: Release the paper.
2) Reverse button (REVERSE) (Non-locking push button)
Function: Feeds paper backward based on the line feed amount set by
ESC 2
and
ESC 3
.
3) Forward button (FORWARD) (Non-locking push button)
Function: Feeds paper forward based on the line feed amount set by
ESC 2
and
ESC 3
.
3.3.2 Power switch (located at the left side of the printer)
Function: Turns on or off the printer power. To start the self-test, hold down the release button and
press this switch.
Note: This switch is located at the left side of the printer. When the printer is turned off using this
switch, the RAM is completely initialized.
3.3.3 DIP switches
1) For serial interface model
Table 3.3.1 DIP Switch 1
DIP Switch
1
Function ON OFF
1 Data receive error Ignored Prints "?".
2 Receive buffer capacity Data buffer 35 bytes Data buffer 512 bytes
3 Handshaking XON/XOFF DTR/DSR
4 Data word length 7 bits 8 bits
5 Parity check Yes No
6 Parity selection Even Odd
7
8
Baud rate selection
Transmission speed selection
Refer to Table 3.3.2.
9 Pin 6: Reset signal Used Not used
10 Pin 25: Reset signal Used Not used
To Next Page
