TM-U295/U295P
Specification
(STANDARD)
27 26
3.7 Paper Sensors
Two types of paper sensors are equipped as follows:
ù
TOF sensor
ù
BOF sensor
3.7.1 Sensors and LED indicators
The paper out LED indicator lights when either the BOF or TOF sensor detects a paper-out, regardless
of whether the sensor is enabled or disabled.
3.7.2 Sensors and printing operation
When a paper-out is detected, whether printing stops or not is selected by
ESC c 4
. The related
sensors are as follows:
ù
TOF sensor
ù
BOF sensor
When printing stops by detecting a paper-out, the printer stops after printing and feeding the current line.
If the panel buttons are disabled, the printer automatically releases the paper and waits for another slip
to be inserted.
3.8 Buffer-full Printing
When more print data is received after processing one line of data, the printer automatically prints the
processed data and feeds the paper one line.

Epson TM-U295 Specifications

General

Color	No
Maximum number of copies	2 copies
Maximum printing width (columns)	42
Dimensions (WxDxH)	180 x 190.5 x 101.5 mm
Power requirements	24 VDC±10%
Connectivity technology	Wired
Printing media thickness	0.09/0.35 µm
Mean time between failures (MTBF)	180000 h
Safety	UL, CSA C22.2 No. 950
Country of origin	Japan
Electromagnetic compatibility	VCCI class A, FCC class A, CE marking
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	1370 mm
Quantity per pallet	120 pc(s)
Quantity per pallet (UK)	160 pc(s)
Master (outer) case width	300 mm
Quantity per pallet layer	24 pc(s)
Master (outer) case height	405 mm
Master (outer) case length	485 mm
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	32 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	270 mm
Package width	235 mm
Package height	185 mm
Package weight	1845 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	191 mm
Width	180 mm
Height	102 mm
Weight	1600 g
