Epson TM-U295 User Manual

EPSON
TITLE
SHEET
REVISION
NO.
SHEETNEXT
F
TM-U295/U295P
Specification
(STANDARD)
50 49
[Reference] Section 3.9.2,
Page Mode Limitations
ESC F
n
[Name] Set/cancel cut sheet reverse eject
[Format] ASCII ESC F
n
Hex 1B 46
n
Decimal 27 70
n
[Range] 0
£
n
£
255
[Description] Sets or cancels the cut sheet reverse eject specified by
FF
.
When n = <
*******
1>B, reverse ejection is set.
When n = <
*******
0>B, reverse ejection is canceled (forward ejection is set
automatically).
[Default]
n
= 0
[Reference]
FF
ESC J
n
[Name] Print and feed paper
[Format] ASCII ESC J
n
Hex 1B 4A
n
Decimal 27 74
n
[Range] 0
£
n
£
255
[Description] Prints the data in the print buffer and feeds the paper by
n
/60 inches (
n
´
approximately
0.423 mm).
[Notes] Sets the print position to the beginning of the line.

Epson TM-U295 Specifications

General

Color	No
Maximum number of copies	2 copies
Maximum printing width (columns)	42
Dimensions (WxDxH)	180 x 190.5 x 101.5 mm
Power requirements	24 VDC±10%
Connectivity technology	Wired
Printing media thickness	0.09/0.35 µm
Mean time between failures (MTBF)	180000 h
Safety	UL, CSA C22.2 No. 950
Country of origin	Japan
Electromagnetic compatibility	VCCI class A, FCC class A, CE marking
Pallet width	1200 mm
Pallet height	1000 mm
Pallet length (UK)	1370 mm
Quantity per pallet	120 pc(s)
Quantity per pallet (UK)	160 pc(s)
Master (outer) case width	300 mm
Quantity per pallet layer	24 pc(s)
Master (outer) case height	405 mm
Master (outer) case length	485 mm
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	32 pc(s)
Quantity per master (outer) case	4 pc(s)
Package depth	270 mm
Package width	235 mm
Package height	185 mm
Package weight	1845 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	191 mm
Width	180 mm
Height	102 mm
Weight	1600 g
