QX50/QX200/QX2000 Manual I: Installation Guide
The Connectors Panel of QX2000
1 Two USB ports to enable the connectivity of USB flash drive.
2 The main power switch is used to apply or remove power from the power supply to the
system. Turning off system power with this button removes the main power but keeps
standby power supplied to the system. Therefore, you must unplug system before servic-
ing.
3 DVD-ROM is used for emergency recovery.
4 Two ETH RJ45 interfaces to attach the QX2000 to the router. These interfaces are placed
in the back panel of QX2000.
