QX50/QX200/QX2000 Manual I: Installation Guide
Connecting the Hardware
For QX50/QX200:
• Verify the product package contents are complete. Refer to the contents sheet included in
the packaging to determine if all the items were shipped in the box.
• Connect analog telephones and fax machines to the FXS ports on the QX’s rear panel. You
may connect up to two analog phones.
• Connect the LAN port on your PC via a straight CAT 5 cable with an RJ45 connector to the
LAN socket of the QX IP PBX.
• Connect the IP phones to the switch and attach it to the LAN socket of the QX IP PBX via a
straight CAT 5 cable with an RJ45 connector.
• Connect the WAN port of the QX IP PBX to the ISP network.
• Power the QX by connecting the power cable to a power strip with surge protection and a
UPS.
• Power up any hub or switch followed by any PC and other devices on the LAN side.
• Check the LEDs: The green WAN LED will blink when cables are connected to these ports
and all devices are powered up. If the green WAN LED does not blink, verify cabling and
ensure that all devices are powered up.
Please Note: CAT 5 cables can be faulty without any visual indication. The LAN and WAN
LEDs verify that the Ethernet connection is established between the end points. If these
LEDs are not illuminated, there is a connection problem between the QX IP PBX and the
other device.
