E124 6 532365 - Rev.A
Translation of the original instructions
ENGLISH
B command on channel 2 (partial motion). Alterna-
tively, channel 2 OMNIDEC can be enabled to activate
a programmable output. The XF (3 pin) plug-in type
accessory module allows various types of FAAC radio
codes to be memorised: SLH/SLH LR, LC/RC, DS. The
various types of radio codes can coexist as long as the
radio controls have the same frequency.
In addition, a quick insertion (5 pin) connector for FAAC
radio/decoder boards is available.
Diagnostics using LEDs, display and Simply Connect
notifications (optional).
Programming There are two menus for programming
from the board, via display and dedicated but-
tons: BASIC and ADVANCED.
In addition, remote programming from Simply Connect
provides a larger number of options, including upload-
ing / downloading the programming and updating
the board FW.
Simply Connect This CLOUD platform allows remote
communication with the automation, with modes spe-
cific for the installer or user. Simply Connect requires
an accessory connectivity module to be plugged in,
which is chosen according to technology used:
- XMB (GSM for mobile, Bluetooth Low Energy
technology)
- XWBL (WiFi, LAN, Bluetooth Low Energy technol-
ogy).
L
Simply Connect requires E124 firmware version FW
4.0 or later.
3.5 TECHNICAL CHARACTERISTICS
1 Technical data
Power supply voltage 198...264/104...126 V~
50/60 Hz
Max power 200 W (4 W in stand-by)
Max. power of each motor 70 W
Max. accessories load 24 V
"
500 mA
Max. BUS 2easy accessories load 500 mA
Max. flashing light load 24 V
"
15 W
IP IP54
Ambient operating temperature -20 … +55°C
The E124 can control one or two 24 V
"
brushed mo-
tors, each having a maximum power of 70 W.
Enclosure the enclosure houses the E124 and the
switching power supply and is designed to house the
emergency battery (optional).
Board cover The cover protects against electric shock
by contact with live parts of the circuit.
Switching power supply with 230/115 V ~ voltage selector
(factory set to 230 V ~) The switching power supply
reduces power consumption in stand-by, keeps the
output voltage stable even in the event of fluctuations
in the mains supply and works over a wide range of
input voltages.
Secondary power supply 24 V
"
If there is no mains power,
rechargeable emergency batteries can be used (the
charger is integrated in the board) or solar panels.
BUS 2easy E124 allows you to connect control and de-
tection devices from the FAAC BUS 2easy range (pulse
generators, encoders, photocells…). In addition,
traditional devices (photocells, sensitive edges) with
an NC contact can be used.
L
BUS 2easy control devices require E124 firmware version
FW 3.2 or later.
Adjustable sensitivity obstacle detection An obstacle that
prevents the leaf from moving can be detected by
monitoring the current absorbed by the motor or using
an encoder (if present).
Encoder An accessory encoder can be used (e.g.
SAFEcoder BUS 2easy or Gatecoder) or one integrated
in the actuator (S800H ENC). The electronic board
detects the angular position and the speed of move-
ment of the leaf via the encoder and is able to detect
the presence of an obstacle.
Adjustable slowdown speed.
2 programmable outputs.
Radio System The E124 is fitted with an integrated two
channel decoding system OmniDEC, for the OPEN A
command on channel 1 (total motion) and the OPEN
