Lumina 16
Technical specifications
57
Power supply
Mains voltage
90Vac – 264Vac
Mains frequency
50/60Hz
Maximum power consumption
45VA
Internal power
24Vdc+5Vdc
16 digital outputs (2x FRM.8)
8x NO+NC contact (potential free)
Max. 2A 60Vdc/30Vac
8x NO-contact (potential free)
Max. 2A 60Vdc/30Vac
Operation
16x manual-0-auto switch
Control
16x LED on front cover
I/O addresses
iMSCM.16
"I/O address".01
IOB.12
Power available for sensors
24Vdc, fused
Max. 200mA
12Vdc, short circuit resistant
Max. 70mA
Power available for sensors and peripheral equipment
24Vdc, short circuit resistant
Max. 500mA
6× analog outputs (AO)
Voltage range
0 – 10Vdc
Maximum load
1mA
Output resistance
570
12× analog inputs (AI)
Type selectable through jumpers
Resistance or voltage
Resistance:
Temperature range sensor type S.7
–50°C to +110°C (–58°F to +230°F)
Accuracy –25°C to +100°C (-32°F to -140°F)
<0.2°C (<0.4°F)
Measuring range for position feedback
0 – 20k
Voltage:
Measuring range (input resistance 100k
0 – 10Vdc
Accuracy
± 15mVdc
8× Digital inputs (DI)
Open contact voltage
12Vdc
Low level
<1.0Vdc
Application: Counter input, min. pulse width 25mSec
Max. frequency 20Hz
Application: Frequency input
Max. frequency 5kHz
16× Digital outputs (DO)
1 – 8 connection for FRM.8 printed circuit board
9 – 16 connection for FRM.8 printed circuit board
Alarm contact
Relay: make-and-break contact, voltage free
Max. 2A 60Vdc/30Vac
Communication
I/O-Net for extra inputs and outputs using I/O-modules.
FNet, Fancom network for intercommunication of control computers and PC connection.
