Fancom LUMINA 16 User Manual

Lumina 16
Technical specifications
58
FDP45
Mains voltage
90Vac – 264Vac
Mains frequency
50/60Hz
Maximum power consumption
45VA
IMSPower supply
Mains voltage
1-phase: 230Vac (-10% till +6%)
3-phase: 400Vac (-10% till +6%)
Mains frequency
50/60Hz
Maximum power consumption
45VA
Fuse electronics (5 x 20mm)
slow blown, 250V T50mA
Inputs
Analog in
Voltage- or temperature measuring
Voltage 0-10V, temperature sensor
type S7 ( -50°C t/m 110°C)
I/O-net
I/O-net
PF (PowerFail)
Make-contact
Position feedback motor
Potentiometer 4K7 (+/- 20%)
Outputs
Relay (2x)
1-phase: 230Vac, max 4A
3-phase: 400Vac, max 4A
Limit switches
Limit switches
Contact (voltage free)
30Vac / 60Vdc - min. 1A
Manual control
Rotary switch
'close-0-aut.-0-open' control
I/O addresses
IMS
"I/O address".02 + .03 + .04
Power supply
Mains voltage
90Vac – 264Vac
Mains frequency
50/60Hz
Maximum power consumption
45VA
Internal power
24Vdc+5Vdc
16 digital outputs (2x FRM.8)
8x NO+NC contact (potential free)
Max. 2A 60Vdc/30Vac
8x NO-contact (potential free)
Max. 2A 60Vdc/30Vac
Operation
16x manual-0-auto switch
Control
16x LED on front cover
I/O addresses
iMSCM.16
"I/O address".01
