1. Direct Mode LED: Indicates the camera is in Direct Mode. When the camera is in Di-
rect Mode, you can connect to the Wi-Fi hotspot created by the camera to connect to
it in areas without access to wireless.
2. Cloud Mode LED: Glows solid green to indicate the camera is connected to a Wi-Fi
network, allows you to connect to the camera from anywhere. Flashing indicates the
camera is connecting to a Wi-Fi network.
3. Temperature/humidity sensor (built-in): Senses the temperature and humidity in
the room.
4. Accelerometer: Senses the motion of the camera.
3.6 Indoor Stand
1. Connector: Allows the stand to connect to the camera.
2. Ball joint: Provides the camera with a flexible range of motion.
3. Expanded battery: Provides extra battery life for the camera.
4. microUSB port: Connect a microUSB cable to the stand for charging the battery in
the camera and stand.
NOTE
While the camera is connected to a computer, you will not be able to connect to it using a mobile
device. Do not connect a USB cable to both the camera and stand at the same time.
5. Mounting plate: Enables the camera to be mounted to a wall. The mounting plate
can be removed from the camera. The camera comes with an additional mounting
plate, so you can keep a permanent mounting position while still having the ability to
move the camera around.
6. Device ID label: Contains the Device ID and QR code used for initial setup using the
mobile app.
NOTE
When performing firmware updates be sure to connect your FLIR FX camera to a power source using
the included USB cable and power adapter.
