56
OptiView XG Network Analysis Tablet
Getting Started Guide
Wireless Adapters 1 & 2
Data Rate 802.11a: 6/9/12/24/36/48/54 Mbps
802.11b: 1/2/5.5/11 Mbps
802.11g: 6/9/12/24/36/48/54 Mbps
802.11n (20 MHz): MCS0-23, up to 216 Mbps
802.11n (40 MHz): MCS0-23, up to 450 Mbps
Operating
Frequency
2.412 ~ 2.484 GHz (Industrial Scientific Medical
Band)
5.170 ~ 5.825 GHz
Security 64/128-Bit WEP Key, WPA, WPA2, 802.1x
Transmit Output
Power*
(Tolerance:±1.5 dBm)
2.4 GHz 802.11b: 16.58 dBm at 2412 MHz
2.4 GHz 802.11g: 17.64 dBm at 2412 MHz
2.4 GHz 802.11 HT20: 27.17 dBm at 2412 MHz
2.4 GHz 802.11 HT40: 23.24 dBm at 2412 MHz
5725 MHz - 5850 MHz
802.11a: 22.69 dBm at 5825 MHz
802.11n HT20: 25.25 dBm at 5745 MHz
802.11n HT40: 23.83 dBm at 5795 MHz.
5150 MHz - 5250 MHz
802.11a: 13.41 dBm at 5220 MHz
802.11n HT20: 13.91 dBm at 5220 MHz
802.11n HT40: 14.06 dBm at 5230 MHz
5250 MHz - 5350 MHz
802.11a: 17.79 dBm at 5260 MHz
802.11n HT20: 18.91 dBm at 5300 MHz
802.11n HT40: 18.56 dBm at 5270 MHz
5470 MHz - 5725 MHz
802.11a: 16.72 dBm at 5500 MHz
802.11n HT20: 18.46 dBm at 5700 MHz
802.11n HT40: 16.49 dBm at 5670 MHz
Receive Sensitivity
(Tolerance: ±2 dBm)
802.11b: 8% PER
-90 dBm
802.11g: 10% PER
-80 dBm
802.11n: 2.4 GHz
10% PER
-72 dBm@HT20
-70 dBm@HT40
802.11a: 10% PER
-78 dBm
802.11n: 5 GHz 10%
PER
-70 dBm@HT20
-63 dBm@HT40
