FUSE SPECIFICATION CHART - VEHICLES BUILT UP TO: 04-01-

2013

Engine Compartment Fuse Box

Circuits protectedFuse ratingFuse

Anti-lock braking system module40 A1

Anti-lock braking system, electronic stability program

module

30 A1

Cooling system fan high speed60 A2

Cooling system fan40 A3

Cooling system fan low speed30 A3

Heater blower30 A4

135
