Fujitsu LIFEBOOK U904 User Manual

Security functions
Trusted Platform Module (TPM) (device-dependent)
TPMTrustedPlatform Module
To use the TPM, you must activate the TPM in the BIOS Setup before the software
is insta lled. The condition for this is that you have assigned at least the supervisor
HDD password (see "
Secu rity functions", Page 46).
Enabling TPM
• Requirement: You have assigned a supervisor HDD password, see "Security functio ns", Page 46.
► Call up the BIOS Setup an
d select the Security menu.
► Mark the TPM S ecurity Chip Setting field and press the Enter key.
► Select Enabled to acti
vate the TPM.

Once you have activated the TPM the Clear Security Chip option appears.
Select Cl ear Secur it
yChipto delete the holde r in the TPM. B y clicking on Enabled,
all secret keys (e.g
. SRK - Storage Root Keys, AIK - Attestation Identity Keys
etc.) generated by
applications are deleted.
Please note that yo
u will then no longe r be able to access the data you have
encrypted with th
e keys based on that holder.
► Select the Exit Sa
ving Changes option in the Exit menu.
► Press th e Enter key and select Yes.

The note book wil
l restart, and TPM will be enabled after the reboot.
Disabling TPM
• Requirement: You have assigned a supervisor HDD password, see "Security functio ns", Page 46.
► Call up the BIOS Setup and select the Security menu.
► Mark the TPM S ecurity Chip Setting field and press the Enter key.
► Select Disabled to deactivat e the TPM.
► Fr om the Exit menu, choose the option Exit Saving Changes.
► Press th e Enter key and select Yes.

Your notebook will now restart and TPM will be disab led.
Fujitsu 51

Fujitsu LIFEBOOK U904 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Housing material	Aluminium, Magnesium
Market positioning	Business
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-4600U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4600 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Motherboard chipset	-
Memory slots	1x SO-DIMM
Internal memory	10 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA III
Storage media	SSD
Card reader integrated	Yes
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Display diagonal	14 \
Display resolution	3200 x 1800 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	1000:1
On-board graphics card ID	0xA16
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4400
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	200 MHz
On-board graphics card DirectX version	11.2/12
On-board graphics card dynamic frequency (max)	1100 MHz
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Keyboard number of keys	85
Processor code	SR1EA
Processor ARK ID	76616
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology version	1.00
Battery capacity	25 Wh
Battery life (max)	10 h
Battery recharge time	2 h
AC adapter frequency	50 - 60 Hz
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Cable lock slot type	Kensington
Password protection type	BIOS, HDD, Supervisor, User
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 85 %
Sustainability certificates	RoHS, ENERGY STAR

Weight and Dimensions

Depth	229.9 mm
Width	329.9 mm
Height	15.5 mm
Weight	- g
