Fujitsu LIFEBOOK U904 User Manual

Appendix
Recovering Your Recovery Image Using Recovery and Utility
(for new hard drive or non-boot
able hard drive)
If you have installed a new h ard drive or your hard drive is not bootable, perform the following s teps.
Note: You will need the Bootable disk and Recovery Ima ge disk set for th is recovery.
1. Pow er on your system. Wh en the Fujitsu logo appears on the screen, press the
Enter
key.
2. In sert the bo otable disk in your DVD drive, then click OK.
3. H ighlight the C D/DVD option from the Boot Menu and press
Enter
.
4. Select CD/DVD boot mode: Se lect UEFI Mode , if applicable and press
Enter
.
While the files are being loaded from the disk, the Fujitsu logo screen appears
followed by a progress bar at the bottom of the screen.
5. C hoose your language, if necessary.
6. T hree tool options appear: Diagnostics, Recovery and Utility.SelectRecovery.
• For W indows 8.1: Select Restore full hard drive
• For Windows 7: Select Restoring the Factory Image (full hard drive recovery)
7. C lick Next to confirm full hard drive restoration. All data on HDD w ill be deleted.
8. Agree to EULA by selecting Agree option and clicking Next.
9. C lick Next on the Recovery Disk Check screen to verify that the bootable
disk has been inserted into the optical drive.
10. The Checking for Recovery Disk screen appears followed by the prompt to insert the
first disk. Click OK to continue. Repeat this step for all disks. After all recovery disks
have been checked and the check has been completed, click Next.
11. Follow the prompt to reinsert the first recovery disk and click Next.
12. C lick OK w hen you receive the final warning informing you that all data on drive
C will be lost. This starts the recovery process.
13. Follow the prompts to insert the next recovery disks and click OK.
14. After the copying of the image to the HDD completes th e restore process is
complete, click Finish to resta rt the system. The computer w ill restart automatically
and then go through the first boot process.
15. Follow the steps listed in “Auto Installation support for essential access
software from backup location” section.
16. Download FSDM (Fujitsu Software Download Manager) from support site and download
all the software applicable to the model and OS using FSDM.
17. Follow the steps listed in “Auto Installation support for essential access
software downloade d from support website.
72 Fujitsu

Fujitsu LIFEBOOK U904 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Housing material	Aluminium, Magnesium
Market positioning	Business
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-4600U
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4600 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Motherboard chipset	-
Memory slots	1x SO-DIMM
Internal memory	10 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA III
Storage media	SSD
Card reader integrated	Yes
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Display diagonal	14 \
Display resolution	3200 x 1800 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	1000:1
On-board graphics card ID	0xA16
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4400
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.3
On-board graphics card base frequency	200 MHz
On-board graphics card DirectX version	11.2/12
On-board graphics card dynamic frequency (max)	1100 MHz
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad
Keyboard number of keys	85
Processor code	SR1EA
Processor ARK ID	76616
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology version	1.00
Battery capacity	25 Wh
Battery life (max)	10 h
Battery recharge time	2 h
AC adapter frequency	50 - 60 Hz
AC adapter output current	3.42 A
AC adapter output voltage	19 V
Cable lock slot type	Kensington
Password protection type	BIOS, HDD, Supervisor, User
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 85 %
Sustainability certificates	RoHS, ENERGY STAR

Weight and Dimensions

Depth	229.9 mm
Width	329.9 mm
Height	15.5 mm
Weight	- g
