4. INPUT/OUTPUT DATA
4.1 Processor Unit
Input and output data handled at the processor unit are shown in the table below.
Input
* Data input cycle must be more than 40 Hz (high speed craft) or 20 Hz (conventional
ships).
Output
** The output sentence can be set on the [TT DATA OUTPUT] menu (see page 3-9).
Data Specification Contents Remarks
Heading signal IEC 61162-2*
Speed signal IEC 61162-1 Ed.4
Navaid data IEC 61162-1 Ed.4 Position, time and
date, datum, course,
speed, wind, current,
depth, temperature,
Navtex, etc.
AIS signal IEC 61162-2
Alarm handling
signal
Contact closure Input from alarm system
IEC 61162-1 Ed.4 Input from alarm system
Data Specification Sentence Remarks
Radar system data IEC 61162-1 Ed.4 RSD, OSD
TT data** IEC 61162-1 Ed.4 TTD, TTM, TLB
Alarm signal IEC 61162-1 Ed.4 Four systems, output con-
tents are selected on the
[ALERT I/F] menu.
Contact closure
Notice for FAR-1518(-BB)/FAR-1528(-BB)
These radars must be interconnected to the following type approved sensors:
EPFS meeting the requirements of the IMO resolution MSC.112(73).
Gyrocompass meeting the requirements of the IMO resolution A.424(XI).
SDME meeting the requirements of the IMO resolution MSC.96(72).
