Furuno FAR-1513-BB Installation Manual

v
EQUIPMENT LIST
Standard supply
Name Type Code No. Qty Remarks
Processor Unit RPU-024 - 1
Control Unit RCU-028 - 1
Display Unit MU-150HD -
Select
one
MU-152 -
MU-190 -
Antenna Unit
(FAR-1513, FAR-
1513-BB)
XN12A-RSB-0070-086A -
Select
one
24 rpm, 1200 mm
XN12A-RSB-0073-086A - 48 rpm, 1200 mm
XN13A-RSB-0070-086A - 24 rpm, 1800 mm
XN13A-RSB-0073-086A - 48 rpm, 1800 mm
Antenna Unit
(FAR-1523, FAR-
1523-BB)
XN12A-RSB-0070-087A -
Select
one
24 rpm, 1200 mm
XN12A-RSB-0073-087A - 48 rpm, 1200 mm
XN13A-RSB-0070-087A - 24 rpm, 1800 mm
XN13A-RSB-0073-087A - 48 rpm, 1800 mm
Antenna Unit
FAR-1518, FAR-
1518-BB)
XN12AF-RSB-120-100 -
Select
one
26 rpm, 1200 mm
XN12AF-RSB-121-100 - 48 rpm, 1200 mm
XN20AF-RSB-120-100 - 26 rpm, 2000 mm
XN20AF-RSB-121-100 - 48 rpm, 2000 mm
Antenna Unit
(FAR-1528, FAR-
1528-BB)
XN20AF-RSB-120-101 -
Select
one
26 rpm, 2000 mm
XN20AF-RSB-121-101 - 48 rpm, 2000 mm
XN24AF-RSB-120-101 - 26 rpm, 2400 mm
XN24AF-RSB-121-101 - 48 rpm, 2400 mm
Installation
Materials
(FAR-1513, FAR-
1513-BB)
CP03-36700 000-028-129
Select
one
10 m signal cable
CP03-36710 000-028-130 15 m signal cable
CP03-36720 000-028-131 20 m signal cable
CP03-36730 000-028-132 30 m signal cable
Installation
Materials
(FAR-1523, FAR-
1523-BB)
CP03-36800 000-028-133
Select
one
10 m signal cable
CP03-36810 000-028-134 15 m signal cable
CP03-36820 000-028-135 20 m signal cable
CP03-36830 000-028-136 30 m signal cable
Installation
Materials
(FAR-1518, FAR-
1518-BB, FAR-1528,
FAR-1528-BB)
CP03-36900 000-028-137
Select
one
15 m signal cable
CP03-36910 000-028-138 20 m signal cable
CP03-36920 000-028-139 30 m signal cable
Installation
Materials
CP03-36500 000-027-862 1 For processor unit, in-
cludes CP03-36501,
DVI-D/D S-LINK (5m)
Installation
Materials
CP03-36510 000-028-881 1 For control unit/proces-
sor unit, includes CP03-
36501, CP03-36601,
DVI-D/D S-LINK (5m)
Spare Parts SP03-18001 001-419-820 1 Fuses (2 pcs.), for DC
power processor unit
Spare Parts SP03-18002 001-419-830 1 Fuses (2 pcs.), for AC
power processor unit
