Default settings
*: Available for B/W-type radars only.
IR ES EA NR
AUTO
SEA
AUTO
RAIN
TARGET
ANALYZER*
HATCHING*
CUSTOM1 1 1 1 OFF MAN-30 MAN-0 OFF OFF
CUSTOM2 1 1 1 OFF AUTO-30 MAN-0 OFF OFF
CUSTOM3 1 1 1 OFF MAN-30 MAN-0 OFF OFF
NEAR 1 1 1 OFF MAN-30 MAN-0 OFF OFF
FAR 1 2 1 OFF AUTO-40 MAN-0 OFF OFF
NEAR BOUY 1 1 2 OFF MAN-30 MAN-0 OFF OFF
FAR BUOY 1 2 2 OFF AUTO-30 MAN-0 OFF OFF
ROUGH SEA 1 OFF 2 OFF MAN-50 MAN-40 OFF OFF
SHIP 1 2 1 OFF MAN-30 MAN-0 OFF OFF
HARBOR 1 OFF 1 OFF MAN-30 MAN-0 OFF OFF
BIRD 1 OFF 1 OFF MAN-30 MAN-0 OFF OFF
ICE 2 OFF OFF OFF MAN-30 MAN-0 OFF OFF
COAST OFF OFF OFF OFF MAN-30 MAN-0 OFF OFF
STC
CURVE
STC
RANGE
LOW
LEVEL
ECHOES
GAIN ACE
ACE
GAIN
VIDEO
CONTRAST
CUSTOM1 3 8 0 85 OFF 50 2-B
CUSTOM2 3 8 0 85 OFF 50 2-C
CUSTOM3 3 8 0 85 ON 50 2-B
NEAR 3 8 0 85 OFF 50 1-B
FAR 3 8 0 85 ON 60 4-B
NEAR BOUY 3 8 0 85 OFF 50 1-C
FAR BUOY 3 8 0 85 OFF 50 4-C
ROUGH SEA 3 9 0 85 OFF 35 2-C
SHIP 3 8 0 85 ON 50 2-B
HARBOR 3 8 0 75 ON 50 1-C
BIRD 3 8 0 85 OFF 50 3-C
ICE 3 7 0 80 OFF 50 1-B
COAST 3 8 0 85 OFF 50 2-C
