Default settings for [PULSELENGTH]
*: These ranges are available for B/W-type radars only.
About the ICE custom setting (optional specification)
0.125 NM
to 0.5 NM
0.75 NM 1 NM* 1.5 NM 2 NM* 3 NM
CUSTOM1 S1 S1 S1 S2 S2 M1
CUSTOM2 S1 S1 S1 S2 S2 M1
CUSTOM3 S1 S1 S1 S2 S2 M1
NEAR S1 S1 S1 S2 S2 M1
FAR S1 S1 S1 S2 S2 M1
NEAR BOUY S1 S1 S1 S2 S2 M1
FAR BUOY S1 S1 S1 S2 S2 M1
ROUGH SEA S1 S1 S1 S2 S2 M1
SHIP S1 S1 S1 S2 S2 M1
HARBOR S1 S1 S1 S2 S2 M1
BIRD S1 S1 S1 S2 S2 M1
ICE S1 S1 S1 S1 S1 S2
COAST S1 S1 S1 S2 S2 M1
4 NM* 6 NM 8 NM* 12 NM 16 NM* 24 NM
CUSTOM1 M1 M2 M2 L L L
CUSTOM2 M1 M2 M2 L L L
CUSTOM3 M1 M2 M2 L L L
NEAR M1 M3 M3 M3 M3 L
FAR M1 M3 M3 L L L
NEAR BOUY M1 M2 M2 M3 M3 L
FAR BUOY M1 M3 M3 L L L
ROUGH SEA M1 M2 M2 M3 M3 L
SHIP M1 M2 M2 L M3 L
HARBOR M1 M2 M2 M3 M3 L
BIRD M1 M2 M2 M3 M3 L
ICE S2 M1 M1 M1 M1 M2
COAST M1 M2 M2 M3 M3 L
The ICE custom setting sets up the radar to detect areas of ice on the sea surface. With
ICE active, the following restrictions or requirements apply:
• For interswitch configurations with a FAR-2xx8 series as the main radar and a FAR-
2xx7 series as the sub radar, ice echoes may not appear correctly on the FAR-2xx7
series screen. Avoid using a FAR-2xx7 series radar as the interswitch sub-radar with
Ice Mode enabled.
• Ice Mode must be enabled from the [RADAR INSTALLATION] menu. See the Instal-
lation Manual for details.
• Dual radar mode must be disabled from the [RADAR INSTALLATION] menu. See the
Installation Manual for details.
• Ice Mode replaces Bird Mode. While Ice Mode is in use, Bird Mode-related settings
and operations are not available.
• Video Contrast settings are fixed to ICE settings when the performance monitor is ac-
tivated while Ice Mode is enabled.
• While Ice Mode is enabled, the following functions are not available:
• Target Analyzer • Rain Echo Hatching • Video Contrast
• Automatic Clutter Elimination (ACE) • Fast Target Emphasis • Trail Hide
