4. TT OPERATION

4-8

2. Press the ENTER key to show the data of the target.

The symbol for the selected TT is displayed at two-times normal size.

To remove the data of a target from a data box, put the cursor on the corresponding

target symbol, then press the CANCEL HL OFF key or USB mouse.

° °

㼀㻾㼁㻱

Vector reference

Vector time

Target no.

Data box

Cursor

TT selected for

data display
