Furuno WR2120 User Manual

S2E-17-0208_OM_WR2120_C
29
2.7. Operation Process
1) Start rainfall observation
Click [Connect] from [Radar operation]
pull-down menu.
Enter the elevation angle of antenna, data
recording and display data settings.
RainMap will display [Connect] at the
bottom-left of screen when the Antenna
Unit (ATU) and Display Processing Unit
(DPU) are connected and communicating.

Furuno WR2120 Specifications

General

Brand	Furuno
Model	WR2120
Category	Radar
Language	English
