Furuno WR2120 User Manual

S2E-17-0208_OM_WR2120_C
70
7. MAINTENANCE
7.1. Troubleshooting
STATE
CONTENT/PROCEDURE
Cannot turn the power on
1. Make sure that the power cable has not loosened.
2. Make sure that the contact of the power cable plug has not stained.
3. Make sure that the power cable has not damaged.
4. Make sure that the circuit breaker in the Junction Unit is “ON”.
Thermo electric air conditioner
stopped
Please call for service.
- No radar echo indication
- SPU Failure
- System Failure
1. Stop radar operation to [Stop motor] from RainMap. Restart the
RainMap if not possible to click the [Stop motor] under [Stop radar
operation] menu because of failure.
[Stop motor] will send a reset command to SPU, MONI-CON, motor driver,
and itself to release from error.
2. Use WR_rebooter to reset the radar hardware & software
3. Turn OFF/ON the circuit breaker in SPU (Refer to section 1.3).
Error code indication
1. Restart RainMap and Radar (turn OFF/ON the power).
2. Call for service and tell error code.
7.2. Error Code List
Code
Content
E001
Abnormality detected in system [Serial Com (MONI-CON)]
E002
Abnormality detected in system [Serial Com (ANTcontrol)]
E003
Abnormality detected in system [Serial Com (ANTmonitor)]
E004
TCP error
E005
Abnormality detected in system [Detected TCP data missing]
E006
Abnormality detected in system [Serial data (ANTmonitor)]
E013
Abnormality detected in system [Motor Control (ACK Start)]
E014
Abnormality detected in system [Motor Control (ACK Stop)]
E016
Abnormality detected in system [Motor Control (ACK INIT0)]
E017
Abnormality detected in system [Motor Control (ACK INIT1)]
E020
Abnormality detected in system [Motor Control (ACK Run)]
E027
Abnormality detected in system [Motor Control (Wait reply from motor1)]
E028
Abnormality detected in system [Motor Control (Wait reply from motor2)]
W039
Abnormality detected in system [Undefined Error]
E040
SPU abnormality [FPGA module access]
E041
SPU abnormality [IO module setting time out]
E042
SPU abnormality [FPGA setting]
E044
SPU abnormality [FAM_PLL lock time out]
E045
SPU abnormality [FAM_clock formation]
E058
SPU abnormality [FPGA module recognition]
E061
SPU abnormality [Tx setting]
E100
Abnormality detected in system [Serial Com (MONI-CON)]
E101
Abnormality detected in system [Serial Com (ANTcontrol)]
E102
Abnormality detected in system [Serial Com (ANTmonitor)]
E200
RFCONV abnormality [PLL unlock]
E210
HPA abnormality [Outside TX power regulation]
E212
HPA abnormality [Outside temperature regulation]
E312
Drive unit failure detected during zero positioning
E313
E314
E315
