OUTLINE OF SYSTEM
This system observes the strength of precipitation, the speed of rain clouds (Doppler speed), and observes
phenomena of rainfall.
Notice:
1. Do not go around the antenna area.
2. While installing antenna on a rooftop of building in urban area, it must be installed in the safety area and
protected by a lightning rod(s) based on IEC 62305.
3. No obstacles should be around the antenna.
Safe distance:
- If H1 is taller than 1.9 meters, it is safe unless directly touching the antenna.
- If H1 is shorter than 1.9 meters, do not enter within a radius of 7.6 meters from the antenna.
Note: It based on the standard human height of 2 meters.
- Refer the Radio Frequency Radiation Hazard on page i.
Note: It is safe to follow this calculated value because it still has some extra safer margin.
e.g.: H
2
(Height) = 2m,
d (Distance between center of the antenna and human) =6m, θ=2° (Minimum azimuth is -2°)
H
2
-0.6+d・tanθ = 2-0.6+6・tan2°=1.6095m<H
1
Therefore, H
1
(Height of radar stand) = 1.6m,
70km
H
1
＞ H
2
- 0.6 + d・tan0
d
θ
H
1
d
H
2
0.6m
