FUTABA 10J User Manual

123
Helicopter
Function
Method
①Callthemenuscreenfromthe
homescreenby pressingthe +
keyfor1second.
＋
② Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
This is the adjustable function rate (AFR) func-
tion when HR3, H-3, HE3, HN3, H-2, H-4, or H4X
is selected as the swash type. The ailerons, eleva-
tors, and pitch steering angle and direction can be
adjusted.
"SWASHAFR"
（WhenswashtypeisH-1,thissettingscreenisnotdisplayed.）
■ Traveladjustmentofeachfunction
＋ −
or
①Selecteachfunctionitemof"RATE"and
settheratebypressingthe+keyor‒
key.
Range：-100 〜 +100%
Default：+50%
● Whenyouwanttoreturnthesetvaluetotheinitialvalue,press
the+keyand‒keysimultaneously.However,polaritydoesnot
return.
SwashAFR
● Selectthesettingitem
withtheJogkey.
Rete
● Dependingontheswashtypethe
screendisplayisdifferent.
● Whenthepolarityischanged,the
directionofoperationisreversed.
NOTE：Ifthesteeringangleistoolarge,linkagebindingmayoccur.
SWASHAFR
SwashAFR
(HELICOPTER)
6:$6+$)5
