FUTABA 10J User Manual

140
Helicopter
Function
Method
①Callthemenuscreenfromthe
homescreenby pressingthe +
keyfor1second.
＋
② Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
The throttle hold function fixes or stops the
engine throttle position by hold switch operation
during an auto rotation dive. Operation can be
set within the -50%
〜
+50% range based on the
throttle trim position.
The switch is changed at the conditions selection
screen. (Initial setting: SwG)
【Holdpositionadjustmentmethod】
● Whenyouwanttolowertheengineidling,settothe"+"directionand
adjustsothatthecarburetorisfullopen.
● Whenmaintainingidling,setthethrottlesticktotheslowpositionand
turntheholdswitchonandoffandsettothenumberatwhichtheservo
doesnotoperate.
NOTE：Whenconnectingthethrottlelinkage,lowerthedigitaltrimtothe
slowestandadjustsothatthecarburetorisfullopen.
"THRHOLD"
THRHOLD
Throttlehold
(HELICOPTER)
Activatingthefunction
holdthrottleposition
● Selectthesettingitemwith
theJogkey.
● WhennotusingthisFunction
selectINH.ThedisplayofOn/
Offisshownwhenactiveand
assignedtoaswitch.
■ Activatingthefunction
① Selectthe"MIX"itemandthen
selectthe"ON"or"OFF"by
pressingthe+keyor‒key.
＋ −
or
● Whenyoudonotusea
function,settothe"INH"side.
■
Holdthrottleposition
＋ −
or
②Selectthe"RATE"itemandthenadjust
theratebypressingthe+keyor‒key.
Range：-50 〜 +50%
Default：0%
● Whenyouwanttoreturnthesetvaluetotheinitialvalue,press
the+keyand‒keysimultaneously.
Throttlehold

CAUTIONS
［NOTE］Priorityisgiventothrottleholdoveridle-up.
● FunctionACT ↔ INHislinkedto
conditionTHR-HOLD,andcanbeset
atanyscreen.
7+5+2/'

FUTABA 10J Specifications

General

Channels	10
Frequency	2.4GHz
Model Memory	30
Display	LCD
Telemetry	Yes
Trainer Port	Yes
Modulation	S-FHSS
