FUTABA 10J User Manual

141
Helicopter
Function
Method
①Callthemenuscreenfromthe
homescreenby pressingthe +
keyfor1second.
＋
② Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
When a governor (CGY750/GY701/GV-1,
etc.) is used, the speed can be adjusted from the
transmitter. CH7 or CH8 or CH9 can be selected as
the speed setting control channel.
When using a separate ON/OFF switch (cut
switch), ON/OFF control uses CH8. In this case,
CH7 or CH9 controls speed setting.
Settingexamples：
● ExampleofsettingthatswitchesthespeedandON/OFFby3positionswitch
Governorspeed
（settingexample）
3position
Adjustmentfromtransmitter
Switch
direction
Setupofrate
R.P.M1：OFF UP 0% 0%（GovernorR.P.M"off"）
R.P.M2：1400 CNTR 50% "50%"
R.P.M3：1700 DOWN 100% "100%"
*Forexample,speed3sets
themaximumspeedtobe
usedandisloweredand
adjustedatthetransmitter.
*Forthetimebeingusethe
initialratesetting.
*Sincespeedadjustmentfromthetransmitter
isratesetting,checkingtheactualspeedat
thegovernordisplayandrememberingits
relationshipisconvenient.
● Switchingthespeedforeachcondition
 Thespeedforeachconditioncanbesetbyselecting"Cond"byswitch.Sincespeedadjustmentfromthe
transmitterisratesetting,fortheactualspeedcheckthegovernordisplay.
● ControllinggovernorON/OFFbyseparateswitch
 Whenaseparateswitchisusedtoturnthegovernoronandoff,switchsettingisperformedby"OFF-CNTRL"
item.
*SpeedandON/OFFswitchsettingsaredifferentdependingonthegovernor.Performthesesettingsin
accordancewiththeinstructionmanualofthegovernorused.
*Atthrottlehold,alwaysconfirmthatthegovernorisOFF.Conversely,whenraisingthespeedvalue,reverse
thepolarityof"CH8".
"GOVERNOR"
GOVERNOR
Governormixing
(HELICOPTER)
Activatingthefunction
Switchselection
Setupofrate
● When"INH",thefunction
cannotbeused.Whenyou
wanttouseCH7asthespeed
settingchannel, select"CH7"
andwhenyouwanttouse
CH8(9),select"CH8(9)".
● Selectthesettingitem
withtheJogkey.
（Rate）
● Theabovescreen showsthecase whenthespeed is
setforeachcondition.
